Canon T90 disassembly – fixing the shutter

This post is to share the steps and pictures for wires connection and parts location involved during the disassembly. I couldn’t fix mine due to the weak magnet, as the contacts are all clean. These steps are taken directly from Canon T90 service manual. You can find out how to remove the main cover from somewhere else, as this post will detail steps after that.

After the front and side cover is removed, I went ahead to remove the door latch components as a lot of guides online indicated that the spring might fly off.

Then the top cover is removed and all wires disconnected

Start text extraction from service manual

Sequence to remove mirror box, shutter block:
1. disconnect gray wire from solder lug, front release side of mirror box, Fig. 4 (or remove screw holding solder lug)

2. unsolder wires, front release side of main flex, Fig. 4
Note: Fig. 29 shows the wire positions to the front of the main flex (upper right-hand corner of drawing).

3. unsolder red and gray wires from self LED, Fig. 4.

4.- remove pressure bar, front flex connector (2 screws), Fig. 4
5. separate top flex section (SP flex) from flex-connector pins
6. remove elastic connector that fits over flex-connector pins
7. desolder main flex from V-BAT pin, front, Fig. 29
8. separate main flex from flex-connector pins
9. remove elastic connector that fits over flex-connector pins
10. unsolder wires, top rewind end, Fig. 28

11. remove switch rubber, top rewind end (large shoulder screw)
12. remove flex screw, top rewind end
13. desolder 2 connections of back-cover switch from main flex, top rewind end
14. separate top rewind end of main flex from camera
15. lift out mode-switch (plastic support) plate, top rewind end
16. desolder DX flex from FD flex, top rewind end (9 connections)
17. desolder FD flex from back-cover switch contact, top rewind end
18. remove eyelens, 2 long screws top

19. remove 3 screws holding external LCD (white screw goes at release end, toward back of camera)

20. unsolder black and red LCD-illuminator wires, top of main flex

21. unfold section of flex with external LCD
22. unsolder black, yellow, and blue sprocket-switch wires from main flex

23. desolder 5 connections of shutter flex from main flex
Note: in early versions of the flex, only the top 3 connections solder directly to the shutter flex. Wires connect the 1st-curtain and 2nd-curtain switch contacts on the shutter flex to the switch-test points on the main flex, Fig. Z8 (brown wire for 1st-curtain switch, white wire for 2nd-curtain switch). On
disassembly, unsolder the wires from the shutter flex

24. disconnect and remove stop-down spring, bottom of minor box
25. remove 2 black mirror-box screws, back by eyelens

26. remove 2 locating screws, front bottom of mirror box
27. lift out mirror box together with main flex
28. remove 2 screws holding plastic support plate, Fig. 10
29. unsolder orange wire from front of shutter block, Fig. 10
30. remove 3 screws holding shutter block (top 2 corners, bottom left-hand corner)
31. lift out shutter block
Note: To charge the mirror boig push forward the charge lever, Fig. 11. Release the mirror by pushing the armature of the release magnet, Fig. 11, away from the core (or push the tab, Fig. 11, toward the front of the mirror box). To return the mirror, disengage the mirror-up latch, Fig. 13. For mechanical operation and troubleshooting of the shutter block, see TROUBLESHOOTING (Testing the shutter block).

End of text extraction from service manual

To energize the shutter solenoid, you can supply 3v to the orange (positive) and black (negative) wire. To access that I desolder more wires, pictures below

Pictures of the mirror box out

DIY SFF low volume mini itx computer case

The custom pc case project was initiated when the off-the-shelve case took too much area and hides the beautiful Asus Strix 980ti.

Case dimension and volume as below

310mm x 115mm x 184mm – 6.56 liters

length is dictated by the length graphics card : 305 + 2 + 2 + 1
depth is by graphics card and PSU : 40 + 65 + 2 + 2 + 2 + 4
height is by motherboard and hard disk : 170 + 10 + 2 + 2

Computer specifications
Motherboard – Asus H110I Plus (mini itx)
Processor – Intel I5 6500 with factory heatsink
RAM – 16GB DDR4
PSU – Silverstone 600W SFX
Graphics card – Asus Strix 980ti (30.5 x 15.22 x 3.98 Centimeter)

On to pictures

Original case not being space efficient
 photo DSC03882_zps855tliti.jpg

Components pulled out
 photo DSC03885_zpsuwanaaz7.jpg

2mm thick L shape aluminum
 photo DSC03903_zps01ngehjo.jpg

The connecting components
 photo DSC03910_zps3kcmmefo.jpg

Putting it together
 photo DSC03912_zpsjtfog2od.jpg

Installing power supply
 photo DSC03914_zpsnumwhijd.jpg

Motherboard is inside
 photo DSC03917_zpsue9ot9hl.jpg

Halfway done
 photo DSC03919_zpskzao36go.jpg

Harddisk is at the bottom
 photo DSC03922_zps9xiwbwoz.jpg

All done
 photo DSC03923_zpshk4bro4r.jpg

 photo DSC03925_zpszgnbgzu7.jpg

 photo DSC03933_zpsbcukk2zj.jpg

 photo DSC03938_zpsumd7ra28.jpg

 photo DSC03939_zpsne7koryo.jpg
